BUSI® MEDICAL is a high production single cylinder sock machine with latch needles in the dial to enable it to produce true rib and plain stitch medical compression socks with compression class 1, 2, 3 and it is provided with full electronic control. The machine is provided with 2 knitting feeds for both plain stitch and true rib. The compression graduation is achieved by using the automatic stiffening, which is available on all the stitch motors, and by graduating the tension of the inlaid elastic yarn. The features of the machine are listed below.
| Textile possibilities | |
|---|---|
| 1x1 true rib welt | Embroidery pattern on a mesh base 4 colors per course plus the ground |
| Double welt | Two colors jacquard pattern on a true rib base |
| Possibility to switch from inlay to knit for the elastic in the same course | Mesh pattern in two feeds |
| Embroidery pattern on a mock rib base 5 colors per course plus the ground | 1x1, 3x1, 5x1 ecc. true rib fabric |
| 4” | 200 | 320 |
| 4 ½” | 226 | 360 |
| 5” | 320 | 400 |
Busi® accepts no liability deriving from improper use of the machinery. The features described in this leaflet are for information only and might be changed without prior notice. The working parameters (e.g. maximum speed) may vary depending on yarn, knitting, lubrication etc
